​Application area of the HTLS tractor rotary tiller

The Victory HTLS rotary tiller is a professional field cultivator for thorough soil cultivation on medium and larger areas, because with a working width of up to 200 cm and an adjustable working depth of - depending on soil conditions - up to 18 cm, the Victory HTLS field cultivator is clearly superior to conventional mounted tillers from other suppliers in this price range.

The HTLS rotary tiller is perfectly suitable for medium tractors between 35 and 70 HP with Cat I and Cat II three-point hitch.

Unlike other field cultivators offered on the market, we use between 42 and 60 of our 720 g heavy blades made of flexible boron steel depending on the working width, which also deliver an optimal result when hard and heavy soils have to be worked with the HTLS field cultivator. There are always 6 blades on one flange of the rotor shaft, so the soil is optimally and easily loosened.

Technology of the HTLS rotary tiller for tractors

The power transmission of the HTLS rotary tiller is not, as with other mounted tillers, done by a maintenance-prone chain or drive belt, but via a heavy, maintenance-free oil bath gear drive, so that the heavy rotor shaft of the rotary tiller runs with low vibration and the blades glide powerfully through the soil.

The rotor shaft speed of the Victory HTLS field cultivator is 270 rpm and thus reliably crushes even hard soils.


Under the heavy housing of the Victory rotary tiller made of up to 6 mm thick steel sheet is the ball-bearing and laser-balanced shaft, on which flanges with six hardened, individually replaceable rotary blades each are arranged at about 25 cm intervals, which loosen the soil evenly.


The universal three-point frame of the Victory HTLS field cultivator has adjustable and movable lower link connections for your Cat I tractor, so that the position of the rotary tiller behind the tractor can be easily shifted, allowing the working width of the mounted tiller to cover the tractor's track width.

The reinforced freewheel gearbox of the HTLS rotary tiller ensures that the heavy shaft can continue to run after switching off the PTO drive without transferring the movement to the tractor.


A driveshaft with adjustable slip clutch is included in the delivery of the HTLS mounted tiller, so you can optimally match tractor and soil conditions with the Victory field cultivator.


The gear oil for bevel and side gearboxes is also included in the delivery of the Victory rotary tiller.

The new, spring-loaded safety rear flap of the rotary tiller is freely adjustable. This allows the HTLS field cultivator to achieve better leveling of the loosened soil.

✅ Side gearbox with maintenance-free oil bath gear drive
✅ Freewheel gearbox protects tractor after driveshaft is disengaged
✅ Easy positioning of the rotary tiller through adjustable Cat-1 lower link mounts (also usable for Cat-2)
✅ Safety rear flap
✅ Safety covers at the front of the HTLS field cultivator
✅ Driveshaft with slip clutch included in delivery
✅ Gear oil included in delivery
✅ Comprehensive German operating manual
✅ Spare parts supply directly via our online shop with exploded view and detailed parts list

We at Victory Tractor are confident that you will not find a rotary tiller with a better price-performance ratio. Please compare our product in detail with other field cultivators.

ATTENTION

For transport logistics reasons, operating fluids such as gear oil are not filled but included with the shipment. Lubrication points also contain NO lubricants! Please pay attention to the corresponding instructions in the German operating manual BEFORE COMMISSIONING.
